In the builder, a branch is a concrete path from the selected source stream to a destination. Each branch can have its own transform logic, filter, destination connection, and schedule.

​
Transform approaches

MantrixFlow provides three SQL-based approaches:
ApproachWhereSource reference
SQL Transform nodeCanvas (between Source and Destination){{ source }}
Normalisation tabDestination panel → NormalisationAutomatic (rename/exclude)
dbt Layer tabDestination panel → dbt Layer{{ source('raw', 'schema__tablename') }}

​
SQL Transform node

Add a Transform node on the canvas and write a SELECT using {{ source }}:
SELECT
  id,
  LOWER(email) AS email,
  first_name || ' ' || last_name AS full_name,
  amount_cents::NUMERIC / 100 AS amount_usd
FROM {{ source }}
WHERE is_deleted = false

​
Normalisation + dbt Layer

For production pipelines, use the Destination panel tabs:
  1. Normalisation tab — Rename or Exclude source columns before data lands in the raw layer.
  2. dbt Layer tab — Write a dbt SQL model on {{ source('raw', 'schema__tablename') }} using the renamed column names.
See Normalisation and dbt Layer for the full reference.

​
A realistic branching example

A commerce team might branch one orders stream two ways:
  • Analytics branch writes cleaned rows to PostgreSQL in analytics.orders_live.
  • Operations branch writes a narrower customer-service view to MySQL in ops.order_lookup.
That pattern keeps one source read while allowing two different SQL destinations to serve different teams.

​
Safe transform workflow

  1. Pick the source table first so previews use the right record shape.
  2. Start with a pass-through (SELECT * FROM {{ source }}) and change one thing at a time.
  3. Use Preview after every meaningful edit.
  4. Save the transform before running the pipeline.
  5. Validate the destination output before turning the schedule on.

​
Good use cases for a transform

  • standardize enum values such as paid, Paid, and PAID
  • derive reporting-friendly columns such as order_date or mrr
  • remove fields that should not leave the source system
  • flatten JSONB payloads before they reach the destination
  • add metadata such as loaded_from or sync_batch_id

​
Filter node

The builder includes a dedicated Filter node that applies a SQL WHERE clause:
is_deleted = false AND status IN ('active', 'pending')
Use the Filter node for simple keep-or-drop logic. Use the Transform node or dbt Layer when you also need reshaping. Current limitation: the filter panel is primarily a configuration surface. Treat source preview, destination preview, and a manual run as the authoritative validation path.
